Rogoz Audio 3QB6 – anti-vibration audio rack

Price (inc. 23% VAT): €4490,00

Ordering

contact hours:
mon-fri: 10.00 – 17.00; sat.: 10.00 – 15.00

Three-leg, six-level design. Sandwich-structured shelves finished in piano white gloss.
The frame is ballast-filled with quartz sand, supplied with an optimally tuned fill, with rear access ports allowing adjustment of both the quantity and type of ballast. Frame finish: white gloss.

Images may also present alternative finish options, illustrating available color and material variations.

The 3QB6 is designed as a slim, multi-level structure with high rigidity, enabling stable and organized placement of multiple audio components within a vertical layout.


Structure and vibration control

Rogoz Audio racks are designed as systems controlling the flow of mechanical energy. The 3QB6 model uses a rigid steel frame tuned through a combination of carbon and alloy steels.

Thick-walled legs made of S235JR steel and crossbars made of S355 steel form a stable load-bearing structure resistant to dynamic loads.

The shelves are decoupled from the frame using dedicated polymer pads with very low mass and density. This material does not promote energy storage, thereby reducing delayed energy release back into the structure.

In practice, this minimizes effects such as ringing and phase-shifted resonances, helping to maintain a more neutral and uncolored mechanical behavior.

Quartz sand ballast further stabilizes the structure and supports the damping of higher frequencies.


Sound performance

In practice, this results in a stable and well-organized presentation, improved bass control, and enhanced clarity and separation in multi-component systems.

TECHNICAL SPECIFICATIONS

• total height – 1140 mm
• total width – 560 mm
• total depth – 550 mm

• leg profile – 40 × 40 mm (closed-section steel profile)
• top shelf – 560 × 550 × 30 mm
• inner shelves – 475 × 510 × 30 mm

• clearance between shelves (from bottom) – 160, 160, 160, 160, 130 mm

• load capacity per shelf – up to 70 kg (total 420 kg)
• ballast – quartz sand


INCLUDED

• 1 steel frame
• 6 shelves (MDF / HDF / MDF)
• 3 adjustable leveling spikes
• 3 floor protection pads
• low-density polymer isolation elements


APPLICATION

• multi-component audio systems
• analog turntables
• digital sources
• amplifiers and preamplifiers


CUSTOM CONFIGURATION

The rack can be manufactured in a configuration tailored to individual requirements — both in terms of dimensions and finish.

Tailored to your system and space

Rogoz Audio racks, speaker stands and isolation platforms are also available in custom dimensions and finishes.

We can adapt the width and depth of rack shelves, platform tops and speaker stand plates, the overall height of racks and speaker stands, and the clearances between rack shelves. We also consider more extensive structural modifications. The scope, feasibility, price and lead time are confirmed before we accept the order.
